XMT-7 15" RTX 4060 I9 13900HX
CPU 13th Generation Intel Core i9-13900HX ( Max Turbo Boost 5.4 GHz ), 8 P-cores & 16 E-cores / 32 threads, 36MB Smart Cache
Chipset Intel HM770 Express Chipset
Display 15.6” QHD (2560x1440) 240Hz, Wide View Angle, 100% DCI-P3, G-Sync Display, Matte Finished
Memory
Supports Dual Channel DDR5
Two 262 pins SODIMM sockets, support for DDR5 up to 4800MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Video Controller
NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support up to 5 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and DisplayPort over Type-C
NVIDIA GeForce RTX 4060 Laptop GPU
- 8GB GDDR6 Video RAM
- NVIDIA Ada Lovelace Architecture
- Microsoft DirectX 12
- GeForce CUDA technology
- Support PCIe Gen4
- Dynamic Boost 2.0
Intel UHD Graphics (Integrated in 13th Gen Core i9 CPU)
- HDR Support
- Rec. 2020 (Wide Color Gamut)
- Microsoft DirectX 12 compatible
Maximum TGP: 140 W (including 25W Dynamic Boost 2.0)
Storage Two M.2 2280 SSD PCIe Gen 4x4 interface (RAID 0/1)
Sound System
High Definition audio interface
S/PDIF digital output
Built-in Array Microphone
Built-in two speakers
Sound Blaster Studio Pro
Keyboard Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad.
Pointing Device Built in Secure Click pad with Microsoft PTP multi-gesture and scrolling function
I/O Ports
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4
1 DisplayPort 1.4 over USB 3.2 Gen2 port (Type C)
1 Thunderbolt 4 Port with Power Delivery DC in (Type C)
2 USB 3.2 Gen 1 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 RJ-45 LAN (10/100/1000/2500Mbps)
Card Reader Micro SD Push-Push Card reader
Slots
Three M.2 Card Slots,
- 1st for WLAN Combo M.2 2230 Card with PCIe / USB / CNVi interface (E key)
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface (M key)
Communication Built-in 2.5 Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
Other Features
Metal top and bottom case
Built-in 2.0M FHD Video Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Virtual Reality ready
Windows Mixed Reality compatible
NVIDIA G-Sync Technology at Dynamic Display Switch mode
Power Full Range 280W AC Adapter, AC-in 100~240V, 50~60Hz, DC output 20V, 14A
Embedded 6 cells Polymer battery pack 80WH
Security
Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology)
TPM 2.0
Area Fingerprint Reader
OS Support Windows 11 (64-bit)
Certificate Windows 11 (64-bit) Logo
HDMI Logo
Dimension 14.10” (w) x 9.45” (d) x 0.98” (h)
5.29 lbs. including Bare bone and 80WH Battery Pack
XMT-7 15" RTX 3070Ti I7 12700H
Processor
12th Gen Intel Core i7-12700H ( 2.3GHz, Max Turbo boost 4.70 GHz ), 6 P-cores & 8 E-cores / 20 thread, 24MB Smart Cache
Memory
Supports Dual Channel DDR4
Two 260Pin SODIMM sockets, support for DDR4 up to 3200MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Display
15.6” QHD (2560x1440) 165Hz, Wide View Angle, 100% DCI-P3 Display, Matte Finished
Graphics
Processor User Switchable between Microsoft Hybrid Graphics Mode or dGPU Mode
Support 5 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and DisplayPort over Type-C
NVIDIA GeForce RTX 3070 Ti Laptop GPU (Full Performance)
- 8GB GDDR6 Video RAM
- Microsoft DirectX 12 Compatible
- NVIDIA PhysX physics Engine
- NVIDIA CUDA Technology
- Support PCIe Gen4
- Maximum TGP: 140 W (including 15W Dynamic Boost 2.0)
Intel Iris Xe Graphics (Integrated in Core i7-12700H Processor)
- Intel Xe Micro architecture
- 8K HDR Support
- Variable Rate Shading
Storage
Two M.2 2280 SSD PCIe Gen4x4 interface (RAID 0/1)
Audio System
High Definition audio interface
S/PDIF Digital output
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Atlas
Pointing Device
Built in Secure Click pad with Microsoft PTP multi-gesture and scrolling function
Keyboard
Multi languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select)
Fully programmable macro capability - customize individual key as hot key / multiple keystrokes in one key
I/O Ports
1 Thunderbolt 4 Port
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4 output Port
1 DisplayPort 1.4 over USB 3.2 Gen2 port (Type C)
2 USB 3.2 Gen1 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000Mbps)
Slots
Micro SD Card reader
Three M.2 Card Slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with PCIe Gen4 x4 interface
- 3rd for SSD M.2 2280 Card with PCIe Gen4 x4 interface
Communication
Built-in Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
Killer Dual Band Wireless-AX 1650X + Bluetooth, M.2 interface
Security
Kensington Lock
Area Fingerprint Reader
Intel PTT (Platform Trust Technology)
Power System
Embedded 6 cells Polymer battery pack 80WH
Full Range AC-in 100~240V, 50~60Hz, 230W AC Adapter, DC output 20V, 11.5A
OS Support
Windows 11 (64-bit)
Certificate
Windows 11 (64-bit) Logo
HDMI Logo
Physical Characteristic
5.29 lbs. including bare bone and 80WH Battery Pack
14.10" (w) x 9.45" (d) x 0.98" (h)
Other Features
Metal top and bottom case
Built-in 2.0M FHD Video Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Virtual Reality ready
Windows Mixed Reality compatible
Specifications are subject to change without notice
XMT-7 15" RTX 4070 I9 13900HX
Processor
13th Gen Intel Core i9-13900HX ( Max Turbo boost up to 5.40 GHz ), 8 P-cores & 16 E-cores / 32 thread, 36MB Smart Cache
Chipset
Intel HM770 Express Chipset
Memory
Supports Dual Channel DDR5
Two 262Pin SODIMM sockets, support for DDR5 up to 4800MHz (Real operation frequency depends on processor)
Expandable up to 64GB, depends on 8GB/16GB/32GB SODIMM module
Display
15.6” QHD (2560x1440) 240Hz, Wide View Angle, 100% DCI-P3, G-Sync Display, Matte Finished
Graphics
Processor NVIDIA Advanced Optimus (Dynamic Display Switching) Technology
Support 5 active displays
Support NVIDIA Surround View via HDMI x1, mini DP x1 and DisplayPort over Type-C
NVIDIA GeForce RTX 4070 Laptop GPU
- 8GB GDDR6 Video RAM
- Microsoft DirectX 12
- NVIDIA CUDA Technology
- Support PCIe Gen4
- Maximum TGP: 140 W (including 25W Dynamic Boost 2.0)
Intel UHD Graphics (Integrated in Core i9-13900HX Processor)
- HDR Support
- Rec. 2020 (Wide Color Gamut)
- Microsoft DirectX 12 compatible
Storage
Two M.2 2280 SSD PCIe Gen 4x4 interface (RAID 0/1)
Audio System
High Definition audio interface
S/PDIF Digital output
Built-in Array Microphone
2 Built-in Speakers
Sound Blaster Studio Pro
Pointing Device
Built-in Secure Click pad with Microsoft PTP multi-gesture and scrolling function
Keyboard
Multi-languages, Single Zone Multi-Color illuminated full size keyboard with numeric pad. (15 colors to select)
I/O Ports
1 HDMI output Port (with HDCP)
1 Mini DisplayPort 1.4 output Port
1 DisplayPort 1.4 over USB 3.2 Gen2 port (Type C)
1 Thunderbolt 4 Port with Power Delivery DC in (Type C)
2 USB 3.2 Gen1 Ports (Type A, 1 x powered USB port, AC/DC)
1 2-in-1 Audio Jack (Microphone / S/PDIF Optical output)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000/2500Mbps)
Card Reader
Micro SD Card reader
Slots
Three M.2 Card Slots
- 1st for WLAN Combo M.2 2230 Card with PCIe and USB interface
- 2nd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
- 3rd for SSD M.2 2280 Card with PCIe Gen 4x4 interface
Communication
Built-in 2.5 Gigabit Ethernet LAN
Intel Dual Band Wireless Wi-Fi 6E AX211 + Bluetooth, M.2 interface
Security
Security (Kensington Type) Lock Slot
Area Fingerprint Reader
Intel PTT (Platform Trust Technology)
Power System
Embedded 6 cells Polymer battery pack 80WH
Full-Range AC-in 100~240V, 50~60Hz, 280W AC Adapter, DC output 20V, 14A
OS Support
Windows 11 (64-bit)
Certificates
Windows 11 (64-bit) Logo
HDMI Logo
Weight and Dimensions
5.29 lbs. including 80WH battery pack
14.10" (w) x 9.45" (d) x 0.98" (h)
Other Features
Metal top and bottom case
Built-in 2.0M FHD Video Camera with TNR (Temporal Noise Reduction)
FlexiCharger
Virtual Reality ready
Windows Mixed Reality compatible
NVIDIA G-Sync Technology at Dynamic Display Switch mode
Specifications are subject to change without notice
